BIM for Infrastructure



The information like components installation, estimation of energy performance can be detailed in the BIM  for Infrastructure. The new parameter can be defined as per the project-specific requirement

Read More
BIM for Infrastructure

BIM for Infrastructure

BIM modelling

URBAN INFRASTRUCTURE PROJECTS :

    • Integration of existing terrain

    • Design Modelling

    • Clash Detection and Coordination

    • Design Review/Visualization

    • Quantity Estimation

    • 4D/5D Simulation

  •

WATER UTILITIES :

    • Potable Water Supply

    • Recycled Water Supply

    • Fire-Fighting

    • Industrial Sewage

    • Residential Sewage

    • Strom Water Drains

  •
  •
BIM modelling
BIM for Infrastructure

ROADS & HIGHWAY: ROADWAYS (PAVEMENT MARKINGS) :

  • Various Kinds of pavement markings, subdivisions of road segments etc can be done as per the design.

MODEL GENERATION :



All available inputs are converted into 3D information-rich models for various analysis purposes. The model can be used for construction sites will all existing and proposed conditions and taking overall safety measures, for better site and logistic planning.

The information like components installation, estimation of energy performance can be detailed in the BIM process. The new parameter can be defined as per the project-specific requirement.

BIM modelling and structure

REINFORCEMENT DETAILS :

  • The team of structural engineers at Techture is adept with reinforcement modeling in all kinds of structures. We have provided the rebar model for infrastructural projects. Also, we have worked extensively in the rebar modeling for flyovers box girders, etc. Techture understands how to read the rebar details provided by the structural engineer, convert them into 3D models, optimize the length of rebar and hence create a bar bending schedule from the particular model.
